Plastic Ppr Pipe

Hot Water PPR High Temp Plastic Pipe PN16 Green Color For Ship Building

Place of Origin:Zhejiang China
Brand Name:DSTHERM
Certification:ISO9001
Model Number:20-160mm
Product description: Ppr pipe, Ppr Fittings, Plastic ppr pipe, plastic pipe, tube,pprct pipe, pprct fittings, Ppr Aluminum pipe, Ppr-Al-Ppr pipe, Ppr Fiber Pipe, Ppr Uv Pipe, Ppr perforated pipe, Ppr stop valve, Ppr Ball
INQUIRY

Hot Water PPR High Temp Plastic Pipe PN16 Green Color For Ship Building

Description

ISO9001 Hot Water PPR Pipe DIN8077/8078 Color customization 20-160mm

PPR Pipe description

PPR pipes are a suitable choice for residential hot water supply systems,PPR pipes are also lightweight and easy to install.

PPR (polypropylene random copolymer) pipe is a type of plastic pipe that is commonly used for hot and cold water supply systems.

PPR pipes are also resistant to corrosion and chemical damage, which helps to prolong their lifespan and reduce the likelihood of leaks or pipe failures.

PPR Pipe Applications

1) Cold and hot water supply systems for civil and industrial constructions, e.g. in

residential buildings, hospitals, hotels, school and office buildings, ship building

2) Drinking water systems and food industry pipe works

3) Central air conditioning system

4) Irrigating system for gardens and green houses

5) Public and sport facilities such as swimming pools and stadiums

6) For rainwater utilization systems

PPR Water Supply Pipe

	PN 1.0MPa	PN 1.6MPa	PN 2.0MPa	PN 2.5MPa
Outer Diameter d_n(mm)	Wall Thickness e_n(mm)	Wall Thickness e_n(mm)	Wall Thickness e_n(mm)	Wall Thickness e_n(mm)
16		1.9	2.2
20	2	2.3	2.8	3.4
25	2.3	2.8	3.5	4.2
32	2.9	3.6	4.4	5.4
40	3.7	4.5	5.5	6.7
50	4.6	5.6	6.9	8.3
63	5.8	7.1	8.6	10.5
75	6.8	8.4	10.1	12.5
90	8.2	10.1	12.3	15
110	10	12.3	15.1	18.3
160	14.6	17.9	21.9	26.6

Product name	PN25 pp materials plastic food grade ppr pipe with red blue color line
Type	ppr plastic pipe
Color	white or customized
MOQ	1000SQM
Thickness	2.0-26.6mm
Raw material	PPR
Country of origin	China
Payment terms	30% T/T as deposit, the balance being paid against copy of B/L.
Application of ppr pipes	Used to hot and cold water supply
Advantage of PPR pipes	Health, non-toxic, resistance to high temperature and high pressure, light weight, wall smooth, long service life, green environmental protection.
Delivery time	Within 15~ 20 days after received your advance payment

Outer Diameter(mm)	Thickness(mm)
Outer Diameter(mm)	S5	s4	S3.2	S2.5(customized)
20+0.3	2.0+0.3	2.3+0.4	2.8+0.4	3.4+0.5
25+0.3	2.3+0.4	2.8+0.4	3.5+0.5	4.2+0.6
32+0.3	2.9+0.4	3.6+0.5	4.4+0.6	5.4+0.7
40+0.3	3.7+0.5	4.5+0.6	5.5+0.7	6.7+0.8
50+0.3	4.6+0.6	5.6+0.7	6.9+0.8	8.3+1.0
63+0.3	5.8+0.7	7.1+0.9	8.6+1.0	10.5+1.2
75+0.3	6.8+0.8	8.4+1.0	10.3+1.2	12.5+1.4
90+0.3	8.2+1.0	10.1+1.2	12.3+1.4	15.0+1.6
110+0.3	10.0+1.0	12.3+1.4	15.1+1.7	18.3+2.0
125+0.3	11.4+1.3	14.0+1.5	17.1+1.9	20.8+2.2
140+0.3	12.7+1.4	15.7+1.7	19.2+2.1	23.3+2.5
160+0.3	14.6+1.6	17.9+1.9	21.9+2.3	26.6+2.8

Hot Water PPR High Temp Plastic Pipe PN16 Green Color For Ship Building 0

Hot Water PPR High Temp Plastic Pipe PN16 Green Color For Ship Building 1

1. High Temperature Resistance:

PPR pipe's maximum sustained working temperature is up to 70°C , the maximum transient temperature is up to 90°C .

2. Heat Preservation:

PPR pipe's low thermal conductivity which is only 1/1500 of brass pipe, and 1/250 of steel pipe.

3. Non-toxic:

no heavy metal additives, our PN25 pp materials plastic food grade ppr pipe with red blue color line would not be covered with dirt or contaminated by bacterium.

4. Corrosion Resistance:

resist chemical matters and electron chemical corrosion.

5. Low Installation Costs:

light weight and ease of installation can reduce installation costs.

6. Longevity: more than 50 years under proper use.

7. Recycled and Environment-friendly.

Tag: ppr plastic water pipe, ppr plumbing pipe, ppr plastic pipe
