Plastic Ppr Pipe

  • Heat Enduring Plastic Ppr Pipe Bacteriological Neutral Iso Ce Standard
  • Heat Enduring Plastic Ppr Pipe Bacteriological Neutral Iso Ce Standard
  • Heat Enduring Plastic Ppr Pipe Bacteriological Neutral Iso Ce Standard
Heat Enduring Plastic Ppr Pipe Bacteriological Neutral Iso Ce StandardHeat Enduring Plastic Ppr Pipe Bacteriological Neutral Iso Ce StandardHeat Enduring Plastic Ppr Pipe Bacteriological Neutral Iso Ce Standard

Heat Enduring Plastic Ppr Pipe Bacteriological Neutral Iso Ce Standard

  • Place of Origin:Zhejiang China
  • Brand Name:DSTHERM
  • Certification:ISO CE
  • Model Number:20-160mm
  • Product description: Ppr pipe, Ppr Fittings, Plastic ppr pipe, plastic pipe, tube,pprct pipe, pprct fittings, Ppr Aluminum pipe, Ppr-Al-Ppr pipe, Ppr Fiber Pipe, Ppr Uv Pipe, Ppr perforated pipe, Ppr stop valve, Ppr Ball
  • INQUIRY

Heat Enduring Plastic Ppr Pipe Bacteriological Neutral Iso Ce Standard

Payment & Shipping Terms

Minimum Order Quantity: 3000 Meters

Price:                             USD

Packaging Details:           Packed by Nylon Bag and Customized

Delivery Time:                10 days/40 feet container

Payment Terms:              L/C, T/T, Western Union

Supply Ability:                100 tons per month

Description

Material: R200P Brand Name: DSTHERM
Shape: Equal Length: 4m / 6m / Or Customized
Certification: ISO/CE Model Number: PN10pa/PN12.5pa/PN16pa/PN20pa/PN25
Thickness: 2.0-22.6mm, 2.0-22.6mm Standard: DIN8077/8078
Color: Green/Grey/White/Blue/Customized Package: Nylon Bag With Customer Logo
Pressure: From PN10 To PN25 Logo: OEM And DSTHERM
High Light:

ppr plastic water pipe, ppr plumbing pipe

High quality PP-R Cold and Hot water Pipe PPR Pipe 20-160mm DIN8077/8088 ISO CE


PPR pipe & fittings for water supply:

  • 1.Material:PPR--original material from Korea
  • 2.Size:20mm to 160mm
  • 3.Color:green /white/coffee or on request
  • 4.Standard:DIN
  • 5.the reasonable price with excellent quality
  • 6.quick delivery settle for the sales planning of customers

PPR products features:

1).Sanitary; innocuity; green architecture material; can be used for purified water pipe

2).Heat-enduring; temperature of the water running through the pipe can reach 95 degree under the long time regular work pressure

3).Erode-enduring; anti-filthy; avoid pipe jam and rust on basin and bathtub

4).Keep warm and save energy: caloric transmit quotiety is 1/200.It is a good facility to keep the pipe warm and save energy.

5).Light ;intensive;t he weight is 1/8 of the metal; compression resistance has reached 5MPa and above; tenacity; able to endure impacts

ADVANTAGES:

1) Healthy, bacteriological neutral, conforming to drinking water standards.

2) High impact strength and resistant to high temperatures(the maximum sustained working

temperature is up to 70 degrees, the maximum transient temperature is up to 95 degrees)

3) Convenient and reliable installation, low construction expenses

4) Excellent heat-insulation property from minimum thermal conductivity

5) Lightweight, convenient to transport and handle, good for labor-saving

6) Smooth inner walls reduce pressure loss and increase flow speed

7) Sound insulation (reduced by 40% compared to galvanized steel pipes)

8) Light colors and excellent design ensure suitability for both exposed and hidden installation

9) Recyclable, environment-friendly, accords with GBM standards


advantages:

  • High Temperature Resistance: the maximum sustained working temperature is up to 70 Degrees Celsius, the maximum transient temperature is up to 95 Degrees Celsius
  • Heat Preservation: low thermal conductivity which is only 1/1500 of brass pipe, and 1/250 of steel pipe
  • Non-toxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium
  • Corrosion Resistant: resist chemical matters or electron chemical corrosion
  • Lower Installation Costs: light weight and ease of installation can reduce installation costs by as much as 50% over metal piping system
  • Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipes
  • Long Life: more than 50 years under normal conditions
  • Recycled and Environment-friendly
  • Characteristics of the PP-R Pipes;
  • Operating life for 20 C temperature and 25 atm pressure conditions is 50 years.
  • They have high resistance to chemical substances.
  • They are resistant to corrosion.
  • They do not cause calcification or oxidation.
  • They do not affect the color, smell or taste of water.
  • They are composed of smooth and shiny inner surface.
  • No diameter narrowing occurs at welding points.
  • They show high welding performance.
  • They provide heat and sound installation.
  • They are hardly flammable. (Ref: DIN 19560 and DIN 4102)
  • They are environment friendly.



PP-R Water Supply Pipe



PN 1.0MPa PN 1.6MPa PN 2.0MPa PN 2.5MPa

Outer

Diameter

dn(mm)

Wall

Thickness

en (mm)

Wall

Thickness

en(mm)

Wall

Thickness

en(mm)

Wall

Thickness

en(mm)

16 1.9 2.2
20 2 2.3 2.8 3.4
25 2.3 2.8 3.5 4.2
32 2.9 3.6 4.4 5.4
40 3.7 4.5 5.5 6.7
50 4.6 5.6 6.9 8.3
63 5.8 7.1 8.6 10.5
75 6.8 8.4 10.1 12.5
90 8.2 10.1 12.3 15
110 10 12.3 15.1 18.3
160 14.6 17.9 21.9 26.6


Product name PN25 pp materials plastic food grade ppr pipe with red blue color line
Type ppr plastic pipe
Color white or customized
MOQ 1000SQM
Thickness 2.0-26.6mm
Raw material PPR
Country of origin China
Payment terms 30% T/T as deposit, the balance being paid against copy of B/L.
Application of ppr pipes Used to hot and cold water supply
Advantage of PPR pipes Health, non-toxic, resistance to high temperature and high pressure, light weight, wall smooth, long service life, green environmental protection.
Delivery time Within 15~ 20 days after received your advance payment

Heat Enduring Plastic Ppr Pipe Bacteriological Neutral Iso Ce Standard 0Heat Enduring Plastic Ppr Pipe Bacteriological Neutral Iso Ce Standard 1
